Thermoplastic Polyurethane Film
Hot Melt
TPU Adhesive Film
Low-temperature bonding, excellent elasticity, and zero adhesive leakage — engineered for seamless garments, waterproof laminates, sport shoes, and precision industrial applications.
85–105°C
Melting Temp
110–120°C
Operating Temp
0.10–0.25mm
Thickness Range
1–100cm
Width Range
Scroll
Product
Precision bonding
for modern materials
A thermoplastic polyurethane hot melt adhesive film that bonds at low temperatures, saving labour cost while delivering excellent strength, flexibility, and wash resistance across a wide range of substrates.
From waterproof outdoor garments to sport shoe fabric laminations and automobile trims, the K-12 TPU film activates cleanly under heat and pressure with zero adhesive bleed. Environmentally friendly and available in widths from 1cm to 100cm.
Width Range
1 – 100 cm
Narrow tape to full sheet width
Thickness
0.10 – 0.25 mm
6 standard gauges available
Roll Length
50 m / Roll
Custom lengths available
Item No.
K-12
Standard grade, hot melt TPU
Shelf Life
6 Months
Stored cool, dry, away from UV
85°C
Low Melt Temperature
300 Pa.s
Viscosity @ 160°C
15–25 g/10min
Melt Flow Index @ 150°C
0.5–1.5 kg/cm²
Operating Pressure
Key Features
Why engineers
specify K-12
The K-12 TPU adhesive film is engineered for productivity — low activation temperature reduces energy cost and cycle time, while its clean melt profile eliminates adhesive bleed that would otherwise require rework.
Low Operating Temperature
Activates between 110–120°C — significantly lower than conventional adhesives. Reduces energy consumption, shortens cycle times, and prevents thermal damage to delicate fabrics and substrates.
Excellent Bond Strength
Delivers outstanding peel and shear strength across a wide range of substrates — fabric, leather, TPU, PVC, metal film, and reflective materials — with no primer required for most applications.
Wash & Dry Laundry Resistance
Bonds maintain integrity through repeated machine washing and dry cleaning cycles — essential for apparel, sportswear, and workwear applications where durability over a garment's lifespan is critical.
No Adhesive Leakage
Controlled melt viscosity (300 Pa.s @ 160°C) prevents bleed-through onto finished surfaces. Keeps seam lines clean and eliminates the rework cost associated with adhesive contamination.
Good Elasticity & Flexibility
The TPU chemistry retains stretch and flexibility after bonding — ideal for seamless underwear, activewear, and stretch fabrics where the adhesive must move with the material without cracking or delaminating.
Environmentally Friendly
Solvent-free hot melt formulation — no VOC emissions during processing. Suitable for facilities with strict environmental compliance requirements and for products targeting eco-conscious end markets.
Technical Data
Product Specifications
Based on current knowledge and experience. Test samples before production use to confirm suitability for your specific substrate and process.
| Property | Value (K-12) | Unit / Rating |
|---|---|---|
| Melting Temperature | 85 – 105 | °C |
| Melt Flow Index@ 150°C | 15 – 25 | g / 10 min |
| Viscosity@ 160°C | 300 | Pa.s |
| Operating Temperature | 110 – 120 | °C |
| Operating Time | 10 – 20 | Seconds |
| Operating Pressure | 0.5 – 1.5 | kg / cm² |
| Resistance to Washing | Good | — |
| Resistance to Dry Laundry | Good | — |
Solvent-Free
Environmentally Friendly
Make in India
Custom Widths & Lengths
Product Range
Available TPU Film Variants
Footwear
TPU Film for Shoes
Hot melt grade optimised for sport shoe upper lamination, mesh fabric bonding, and toe reinforcement. Maintains flexibility under repeated flexion.
● Wide Format
1220mm Transparent TPU Film
Full-width sheet format for large-format lamination: automotive trim panels, plywood overlay, reflective material lamination, and metal film bonding.
Mid Format
610mm Transparent TPU Film
Standard-width roll for garment manufacturing: waterproof zippers, seamless pockets, fly constructions, and seamless mobile phone case lamination.
Industrial
Hot Melt TPU Adhesive Film
General-purpose grade for conductive fabric bonding, PVC lamination, reflective tape, and industrial substrate joining. Supplied in custom widths 1–100cm.
Processing Guide
How to apply the film
01
Select Film Grade & Width
Choose the appropriate thickness (0.10–0.25mm) and width (1–100cm) for your substrate. Thinner gauges suit lightweight fabrics; heavier gauges are used for leather and automotive trim bonding.
02
Position Film Between Substrates
Place the TPU film cleanly between the two layers to be bonded. No primer or pre-treatment required for most fabric, leather, and TPU substrate combinations.
03
Apply Heat & Pressure
Set your machine to 110–120°C operating temperature, 0.5–1.5 kg/cm² pressure, and 10–20 second dwell time. Compatible with fusing machines, heat rollers, flat-bed heat presses, high-frequency machines, laser cutters, and hand irons.
04
Cool & Inspect
Allow the bond to cool to room temperature before handling. The bond line should be clean with no adhesive bleed. Test peel strength to confirm settings are optimal for your specific substrate pair.
Compatible Machines
Fusing Machine
Heat Roller Machine
Flat Bed Heat Press
High-Frequency Machine
Laser Cutting Machine
Hand Iron
Use Cases
Where TPU film
is applied
From high-performance outdoor garments to precision industrial laminates, the K-12 TPU adhesive film delivers consistent performance wherever a clean, flexible, wash-resistant bond is required.
Seamless Outdoor Garments
Waterproof zippers, seamless pockets, fly seams — clean bonds that flex with the garment through repeated washing cycles.
Sport Shoes
Mesh fabric lamination, upper reinforcement, and sole bonding for performance footwear.
Seamless Underwear
Stretch-compatible bonding that moves with the fabric — no stitching, no chafing seam lines.
↗
TPU & Leather Lamination
Strong, flexible bond between TPU films and natural or synthetic leather panels.
↗
Automobile Trims
Interior panel lamination, reflective material bonding, and PVC surface overlay for automotive interiors.
Storage & Handling
6-Month Shelf Life
Unopened rolls maintain full adhesive performance for six months from date of manufacture when stored correctly.
Cool & Dry Conditions
Store in a cool, dry environment below 25°C with controlled humidity. Avoid storage near heat sources, steam, or condensation.
Avoid Direct UV Exposure
Keep rolls wrapped and protected from direct sunlight and UV radiation, which can degrade the TPU matrix and reduce adhesive performance over time.
FAQ
Common questions answered
What thickness should I choose for my application?
Use 0.10–0.12mm for lightweight sheer fabrics and seamless underwear. Choose 0.15–0.18mm for standard garment bonding and shoe uppers. Opt for 0.20–0.25mm for heavier substrates such as leather, PVC, automotive trim panels, and industrial laminates.
Can this film be used with a regular iron?
Yes. A household or industrial iron set to 110–120°C with a pressing cloth to protect the fabric surface is suitable for small-scale use and sampling. For production, a flat-bed heat press or heat roller machine gives more consistent results.
Is the film compatible with conductive fabrics?
Yes. The K-12 TPU film is specified for use with conductive fabric — it bonds without compromising the fabric's surface conductivity when applied at the correct temperature and pressure settings.
Do you supply custom widths narrower than 1cm?
Our standard range starts from 1cm. For very narrow tape applications below 1cm, please contact us — we can advise on slitting options or recommend the closest standard narrow-width format for your process.
How long does the bond take to reach full strength?
The bond is formed during the 10–20 second dwell under heat and pressure. Full strength is achieved once the assembly cools to room temperature — typically 1–2 minutes. Avoid stress on the bond line during cooling.
Find the right
TPU film for your process
Custom widths from 1cm to 100cm, six thickness options, and 50-metre rolls — or tell us your specification and we'll confirm the right grade. Samples available on request.
Solvent-Free
Custom Widths
Eco Friendly
Make in India
